P4mm Architecture Outdoor LED Advertising LED Display Screen Excellent Color Uniformity

Place of Origin Shen Zhen China
نام تجاری AVOE LED
گواهی CE RoHS
Model Number AE-P4OFRGB
Minimum Order Quantity 5sqm
قیمت negotiable
Packaging Details Flight case, Plywood case
Delivery Time 10 working days after receiving the payment
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 10K sqm per month

برای نمونه ها و کوپن های رایگان با من تماس بگیرید.

واتساپ:0086 18588475571

ویچت: 0086 18588475571

اسکایپ: sales10@aixton.com

اگر شما هر گونه نگرانی دارید، ما 24 ساعت کمک آنلاین ارائه می دهیم.

x
جزئیات محصول
Name Outdoor LED Advertising Screen Pixel Pitch(mm) 4 mm
Pixel Density(pixels/㎡) 62500dot/m2 Configuration 1R1G1B
Viewing Angle(deg.) H:140°, V:140° Module size 320mm*160mm
Usage Outdoor,subway station,highway station advertising,train station Screen dimension Customized Size
Tube chip color Full Color Display function Video,animation,graphics
Brightness 6500cd/sqm Warranty 5 years
Application Outdoor Advertising Led,Advertising,Outdoor,HOTEL,Advertising/stage rental/Commercial event Life span 100000 hours
Color RGB,Full-color,16.7M,1R1G1B Product name led display screen
Led chip Kinglight گواهی CE,UL,CCC,ROHS,GS
Cabinet size 960*960*128mm Input voltage AC 110-240V
برجسته کردن

commercial advertising led display,led street display

,

led street display

پیام بگذارید
توضیحات محصول
P4mm Architecture Outdoor LED Advertising LED Display Screen Excellent Color Uniformity​

Product Features:

1, IP65 weather rating, ensures great quality outputs in every condition.
2, Wide color range, excellent color uniformity
3, Stable performance:superior anti UV, sulfide resistant ability, can be long-term used in outdoor
4, SMD LEDs ensure large viewing angle, up to 110° horizontally and 110° vertically.
Image no distortion, no color cast in any angle within this range, reaches to more audiences.
5, Three anti-protection: anti-corrosion, anti-static, moisture, shock, greatly improving the reliability of the product.
6.Perfect uniformity and no mosaic.


Applications:

Proled LED Billboard Displays are charaterized by high brightness, reliability and durability,ect.

Widely usage,suach as commercial street,shopping mall,train station,government,plaza,high way etc.


Parameters
Unit ModuleItemParameter
Model NumberAE-P4OFRGB
Module size320mm*160mm
Pixel pitch4mm
Pixels Density62500dot/m2
Pixel configuration1R1G1B
Package modeSMD1921
Pixel resolution80dots(W)*40dots(H)
Max Power27.5W
Module thickness16mm
Weight0.58kg
Drive typeConstant drive
Scan mode1/10
Port typeHUB75
Brightness of white balance≥6000~6500cd/m2

LED
Cabinet


Dimension960*960
Monomer Module Number18pcs
Power supply5V/60A*3 pcs
Thermal dischargefan 2pcs
Pixel per cabinet960mm*960mm
Best viewing distance4M~10M
Best viewing angle110°(W) 110°(H)
Temperature

working:-20℃~+50℃

Relative humidity10%-95%
Thickness100mm
PowerWorking voltageAC220V±10%
Average Power consumption325W/㎡
Max .Power consumption≤975W/㎡
Current≤20mA(single LED)
Control systemCPUPentium4 or above P4
Operation systemWIN98/2000/NT/XP/WIN7
Control methodSynchronization

Main technical
parameter

Driving deviceConstant drive IC
Refresh frequency≥1920HZ
Grey scale/colors4096gray level/16.7M colors
MTBF≥100000hours
Power switchAutomatic switch
Display Mode≥800*600/1024*768
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to AVOE.
