Nationstar SMD1921 AVOE Outdoor LED Advertising Screen P4 27.5W
Place of Origin | Shen Zhen China |
---|---|
نام تجاری | AVOE LED |
گواهی | CE RoHS |
Model Number | AE-P4OFRGB |
Minimum Order Quantity | 5sqm |
قیمت | negotiable |
Packaging Details | Flight case, Plywood case |
Delivery Time | 10 working days after receiving the payment |
Payment Terms | T/T, L/C, Western Union, MoneyGram |
Supply Ability | 10K sqm per month |

برای نمونه ها و کوپن های رایگان با من تماس بگیرید.
واتساپ:0086 18588475571
ویچت: 0086 18588475571
اسکایپ: sales10@aixton.com
اگر شما هر گونه نگرانی دارید، ما 24 ساعت کمک آنلاین ارائه می دهیم.
xName | Outdoor LED Advertising Screen | Pixel Pitch(mm) | 4 mm |
---|---|---|---|
Pixel Density(pixels/㎡) | 62500dot/m2 | Configuration | 1R1G1B |
Drive type | Constant drive | Max Power | 27.5W |
Usage | Outdoor,subway station,highway station advertising,train station | Screen dimension | Customized Size,960*960 |
Tube chip color | Full Color | Display function | Video,animation,graphics |
Brightness | 6500cd/sqm | Warranty | 5 years |
Application | Outdoor Advertising Led,Advertising,Outdoor,HOTEL,Advertising/stage rental/Commercial event | Life span | 100000 hours |
Color | 1R1G1B | Module size | 320x160mm |
Product name | led display screen | Led chip | Kinglight |
گواهی | CE,UL,CCC,ROHS,GS | Cabinet size | 960*960*128mm |
Input voltage | AC110V - AC240V | ||
برجسته کردن | SMD1921 AVOE Outdoor LED Advertising Screen,AVOE Outdoor LED Advertising Screen,27.5W Led Outdoor Advertising Board,AVOE Outdoor LED Advertising Screen,27.5W Led Outdoor Advertising Board |
1. LEDs. we select super led tips with high brightness, broad viewing angle(H140degree, V140degree), all the LEDs are ageing for 72 hours before assembly,
when in modules, also aging for 72 hours, after assembly into a screen, still aging 72 hours. so the final LEDs are aging at least for 216 hours, up to 9 days.
2. Modules. we use SMD1921 3in1 pixel configuration to realise high brightness. you may find some lower price suppliers but also same brightness. if you note, maybe they use is not Nation star LEDs lamp, in this case, can cut down much cost but also cut down the life of the display. why? because to reach the same brightness and better waterproof, it is big square lamps from nation star unique design can do it. and our modules case is PVC, which is more durable and have a stronger ability in bask, anti-ultraviolet and Difficult to deformation than Plastic ones.
3. Cabinets. they are used in galvanized steel, or super lightweight Magnesium alumnium die casting cabinets, anti-salt, anticorrosive and waterproof.
4. Screen. use state-of-the-art LED drive IC-ICN2038S, brightness can up to 8000cd/m2, live color video and vivid image with 256 grey level. for outdoor led displays, all of them are IP65 and designed to withstand harsh environmental conditions, such as sun glare, heat, cold, and humidity. you can see more details in the quotation.
5. Packing: anti-shaking wooden case or road flight cases, which is lighter than normal wooden case but more protective to the goods.
6. Spare parts for free. our screen's scotoma rate is below 0.0002, but To prevent accidental, we provide some free spare parts according to
the size of screen.
7. Warranty for 24 months.
8. Technology support: we have full hardware and software files available for all you need, we are here to working for you.
Applications:
Proled LED Billboard Displays are charaterized by high brightness, reliability and durability,ect.
Widely usage,suach as commercial street,shopping mall,train station,government,plaza,high way etc.
Unit Module | Item | Parameter |
Model Number | AE-P4OFRGB | |
Module size | 320mm*160mm | |
Pixel pitch | 4mm | |
Pixels Density | 62500dot/m2 | |
Pixel configuration | 1R1G1B | |
Package mode | SMD1921 | |
Pixel resolution | 80dots(W)*40dots(H) | |
Max Power | 27.5W | |
Module thickness | 16mm | |
Weight | 0.58kg | |
Drive type | Constant drive | |
Scan mode | 1/10 | |
Port type | HUB75 | |
Brightness of white balance | ≥6000~6500cd/m2 | |
LED Cabinet
|
Dimension | 960*960 |
Monomer Module Number | 18pcs | |
Power supply | 5V/60A*3 pcs | |
Thermal discharge | fan 2pcs | |
Pixel per cabinet | 960mm*960mm | |
Best viewing distance | 4M~10M | |
Best viewing angle | 110°(W) 110°(H) | |
Temperature |
working:-20℃~+50℃ |
|
Relative humidity | 10%-95% | |
Thickness | 100mm | |
Power | Working voltage | AC220V±10% |
Average Power consumption | 325W/㎡ | |
Max .Power consumption | ≤975W/㎡ | |
Current | ≤20mA(single LED) | |
Control system | CPU | Pentium4 or above P4 |
Operation system | WIN98/2000/NT/XP/WIN7 | |
Control method | Synchronization | |
Main technical parameter |
Driving device | Constant drive IC |
Refresh frequency | ≥1920HZ | |
Grey scale/colors | 4096gray level/16.7M colors | |
MTBF | ≥100000hours | |
Power switch | Automatic switch | |
Display Mode | ≥800*600/1024*768 |
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to AVOE.
