Nationstar SMD1921 AVOE Outdoor LED Advertising Screen P4 27.5W

Place of Origin Shen Zhen China
نام تجاری AVOE LED
گواهی CE RoHS
Model Number AE-P4OFRGB
Minimum Order Quantity 5sqm
قیمت negotiable
Packaging Details Flight case, Plywood case
Delivery Time 10 working days after receiving the payment
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 10K sqm per month

برای نمونه ها و کوپن های رایگان با من تماس بگیرید.

واتساپ:0086 18588475571

ویچت: 0086 18588475571

اسکایپ: sales10@aixton.com

اگر شما هر گونه نگرانی دارید، ما 24 ساعت کمک آنلاین ارائه می دهیم.

x
جزئیات محصول
Name Outdoor LED Advertising Screen Pixel Pitch(mm) 4 mm
Pixel Density(pixels/㎡) 62500dot/m2 Configuration 1R1G1B
Drive type Constant drive Max Power 27.5W
Usage Outdoor,subway station,highway station advertising,train station Screen dimension Customized Size,960*960
Tube chip color Full Color Display function Video,animation,graphics
Brightness 6500cd/sqm Warranty 5 years
Application Outdoor Advertising Led,Advertising,Outdoor,HOTEL,Advertising/stage rental/Commercial event Life span 100000 hours
Color 1R1G1B Module size 320x160mm
Product name led display screen Led chip Kinglight
گواهی CE,UL,CCC,ROHS,GS Cabinet size 960*960*128mm
Input voltage AC110V - AC240V
برجسته کردن

SMD1921 AVOE Outdoor LED Advertising Screen,AVOE Outdoor LED Advertising Screen,27.5W Led Outdoor Advertising Board

,

AVOE Outdoor LED Advertising Screen

,

27.5W Led Outdoor Advertising Board

پیام بگذارید
توضیحات محصول
NationstarSMD1921 P4 AVOE LED commercial advertising display screen1/10 Scan​

Product Features:

1. LEDs. we select super led tips with high brightness, broad viewing angle(H140degree, V140degree), all the LEDs are ageing for 72 hours before assembly,

when in modules, also aging for 72 hours, after assembly into a screen, still aging 72 hours. so the final LEDs are aging at least for 216 hours, up to 9 days.



2. Modules. we use SMD1921 3in1 pixel configuration to realise high brightness. you may find some lower price suppliers but also same brightness. if you note, maybe they use is not Nation star LEDs lamp, in this case, can cut down much cost but also cut down the life of the display. why? because to reach the same brightness and better waterproof, it is big square lamps from nation star unique design can do it. and our modules case is PVC, which is more durable and have a stronger ability in bask, anti-ultraviolet and Difficult to deformation than Plastic ones.



3. Cabinets. they are used in galvanized steel, or super lightweight Magnesium alumnium die casting cabinets, anti-salt, anticorrosive and waterproof.



4. Screen. use state-of-the-art LED drive IC-ICN2038S, brightness can up to 8000cd/m2, live color video and vivid image with 256 grey level. for outdoor led displays, all of them are IP65 and designed to withstand harsh environmental conditions, such as sun glare, heat, cold, and humidity. you can see more details in the quotation.



5. Packing: anti-shaking wooden case or road flight cases, which is lighter than normal wooden case but more protective to the goods.



6. Spare parts for free. our screen's scotoma rate is below 0.0002, but To prevent accidental, we provide some free spare parts according to

the size of screen.



7. Warranty for 24 months.



8. Technology support: we have full hardware and software files available for all you need, we are here to working for you.



Applications:

Proled LED Billboard Displays are charaterized by high brightness, reliability and durability,ect.

Widely usage,suach as commercial street,shopping mall,train station,government,plaza,high way etc.


Parameters
Unit Module Item Parameter
Model Number AE-P4OFRGB
Module size 320mm*160mm
Pixel pitch 4mm
Pixels Density 62500dot/m2
Pixel configuration 1R1G1B
Package mode SMD1921
Pixel resolution 80dots(W)*40dots(H)
Max Power 27.5W
Module thickness 16mm
Weight 0.58kg
Drive type Constant drive
Scan mode 1/10
Port type HUB75
Brightness of white balance ≥6000~6500cd/m2

LED

Cabinet



Dimension 960*960
Monomer Module Number 18pcs
Power supply 5V/60A*3 pcs
Thermal discharge fan 2pcs
Pixel per cabinet 960mm*960mm
Best viewing distance 4M~10M
Best viewing angle 110°(W) 110°(H)
Temperature

working:-20℃~+50℃

Relative humidity 10%-95%
Thickness 100mm
Power Working voltage AC220V±10%
Average Power consumption 325W/㎡
Max .Power consumption ≤975W/㎡
Current ≤20mA(single LED)
Control system CPU Pentium4 or above P4
Operation system WIN98/2000/NT/XP/WIN7
Control method Synchronization

Main technical

parameter

Driving device Constant drive IC
Refresh frequency ≥1920HZ
Grey scale/colors 4096gray level/16.7M colors
MTBF ≥100000hours
Power switch Automatic switch
Display Mode ≥800*600/1024*768

Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to AVOE.
