6000cd/Sqm Commerical Advertising LED Display SMD3535 Aluminum VGA DVI P10

Place of Origin Shen Zhen China
نام تجاری AVOE LED
گواهی CE RoHS
Model Number AE-P10SMD
Minimum Order Quantity 5sqm
قیمت negotiable
Packaging Details Flight case, Plywood case
Delivery Time 10 working days after receiving the payment
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 10K sqm per month

برای نمونه ها و کوپن های رایگان با من تماس بگیرید.

واتساپ:0086 18588475571

ویچت: 0086 18588475571

اسکایپ: sales10@aixton.com

اگر شما هر گونه نگرانی دارید، ما 24 ساعت کمک آنلاین ارائه می دهیم.

x
جزئیات محصول
Name Outdoor Fixed LED Display Pitch 10mm
Pixel density 10000 dots/sqm Brightness 6000cd/sqm
Pixel configuration RGB 3-in-1 Module dimension 320*160mm
Cabinet size 960*960mm LED type SMD3535
برجسته کردن

6000cd/Sqm Commerical Advertising LED Display,SMD3535 Commerical Advertising LED Display,VGA DVI Outdoor Fixed LED Screen

,

SMD3535 Commerical Advertising LED Display

,

VGA DVI Outdoor Fixed LED Screen

پیام بگذارید
توضیحات محصول

P10 full color outdoor LED Display for large commerical advertising Aluminum cabinet 960*960mm​



Features:


Display contents real-time updates, high brightness, high definition, size and shape can be designed upon client's actual requirement, exquisite, vivid display effects, big viewing angle etc.
The full color AVOE LED Display has brought us a colorful world, LED display attract more viewers for less cost than other standard media using targeted messages that capture your audience with light, motion and color.



Parameters

Specification of P10 Outdoor Fixed LED Display
Module
Dimention (w*h) 320x160mm Resolution (w x h) 32x16
Pixel pitch 10mm Pixel Density 10000 dots/㎡
Pixel Configration RGB 3-in-1 LEDs Type SMD3535
Cabinet
Dimensions(w* h)(mm) 960*960mm Module Quantity(PCS) 18
Physical Resolution (w x h) 96*96 Physical Pixels (total) 9216
Weight/Cabinet (kg) 40 Material Iron/aluminum
Average Power/㎡(watts) 300W Max Power/㎡(watts) 800W
Parameter Value
Brightness ≥ 6000 cd/㎡
Viewing Angle Horizontal 140(+70/-70) deg. Vertical 140(+70/-70)deg.
Best Viewing Distance 6-250meters
Brightness Control 256 level
Gray scale 14bits
Refresh frequency ≥ 1920Hz
Driving mode 1/4 scan constant current driving
Input power frequency 50 or 60 Hertz
Input Voltage 110 ~ 240 Volt
Blind spot rate <1/10000
Lifetime at 50% brightness 100000 hours
Ingress Protection IP65/IP54
Operating temperature ﹣20 ~﹢50 ℃
Operating humidity 10% ~ 90%
Control distance CAT6 cable:<100 m; Single mode fiber:<10 km
Signal input format AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI
Operating system Windows (2007/XP/Vista/7/8/10)



Widely applications:


Mainly used to do outdoor advertisement just like TV, in addition, it also can be used to play the Events, Showing, Cinema, Sports, etc.
